BIOBASE BH-HA310 Hematology Analyzer

Hover to zoom, click for full screenTap to zoom

Accurate results for better diagnosis. Three part hematology analyzer with 21 parameters, 3 histograms and a 9.7 inch touch screen.

Brand: BIOBASE
Model: BH-HA310
Price: Price on request

1 year warranty5 years service

Get a Quote Ask on WhatsApp

Or call our product specialist: +88 01717 883 543

Overview

Accurate results for better diagnosis. Three part hematology analyzer with 21 parameters, 3 histograms and a 9.7 inch touch screen.

Key features

Complete blood count: WBC, RBC, HGB, HCT, PLT and 21 parameters
60 samples per hour
Venous and capillary 10 microlitre, prediluted 20 microlitre
9.7 inch touch screen with an easy interface
Bi-directional LIS support
Impedance method with colorimetric HGB

Supplied by Capstone International Ltd. with installation, operator training, 1 year warranty and 5 years service.

Specifications

Parameters	21 (WBC, MID#, LYM#, GRAN#, MID%, LYM%, GRAN%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, P-LCR, P-LCC)
Histograms	3 (WBC, RBC, PLT)
Throughput	60 samples per hour
Sample volume	Venous 10 microlitre, capillary 10 microlitre, prediluted 20 microlitre
Principle	Impedance, colorimetric HGB
Display	9.7 inch touch screen
LIS	Bi-directional

What it is used for

Complete blood count (CBC) with 3 part differential

Anaemia, infection and platelet tests

Clinics, hospitals and diagnostic centres

Daily routine with 60 samples per hour

How to use

1
Collect blood in an EDTA tube and mix it gently.
2
Switch on the analyzer and let it finish the start up cleaning and background check.
3
Run the daily quality control sample and check it passes.
4
Enter the patient ID and choose the mode (venous, capillary or prediluted).
5
Place the sample under the probe and press the aspirate key.
6
Read the results and histograms on the screen, then print or send them to the LIS.
7
At the end of the day run the shutdown cleaning.

Our engineers train your staff on site after installation. These steps are a short guide; always follow the operator manual supplied with the machine.
